| SPECIFICATIONS |
| Voltage
ratings: |
AC: |
600
Volts |
DC: |
Contact
Shop |
| |
|
| Interrupting
ratings: |
AC: |
200,000
amperes rms symmetrical. |
| |
300,000
amperes rms symmetrical (Littelfuse self-certified) |
| |
|
| Ampere
range: |
8/10
- 600 amperes |
| Approvals: |
UL
Listed Class J Fuses per UL 248 (formerly 198C) |
| |
(File No. E81895). |
| |
| |
CSA
certified HRCI-J per C22.2 #106 (File No. LR29862) |
| |
| AMPERE
RATINGS |
8/10 |
21/4 |
4 |
8 |
20 |
50 |
110 |
250 |
1 |
21/2 |
41/2 |
9 |
25 |
60 |
125 |
300 |
11/4 |
28/10 |
5 |
10 |
30 |
70 |
150 |
400 |
11/2 |
3 |
56/10 |
12 |
35 |
80 |
175 |
450 |
16/10 |
32/10 |
6 |
15 |
40 |
90 |
200 |
500 |
18/10 |
31/2 |
7 |
171/2 |
45 |
100 |
225 |
600 |
2 |
|
|
|
|
|
|
|
|
Example
part number (series & amperage): JTD 60 ID |
| |
| RECOMMENDED
FUSE BLOCKS |
LJ600
series |
|
| Refer
to Fuse Block section of this catalog for additional information. |
