| SPECIFICATIONS |
| Voltage
ratings: |
AC: |
600
Volts |
DC: |
250
Volts |
(CCMR 2/10 --- 2A) |
| |
|
(CCMR
4 1/2 --- 10A) |
| |
|
(CCMR
35 --- 60A) |
| |
300
Volts |
(CCMR
2 1/4 --- 4A) |
| |
500
Volts |
(CCMR
12 --- 30A) |
| |
|
|
| Interrupting
ratings: |
AC: |
200,000
amperes rms symmetrical. |
| |
300,000
amperes rms symmetrical (Littelfuse self-certified) |
DC: |
20,000
amperes |
| |
|
| Ampere
range: |
2/10
- 60 amperes |
| Approvals: |
UL
Listed Time-Delay Class CC fuses per UL 248 |
| |
(Formerly UL 198C) (File No. E81895) --- 2/10 -- 30A |
| |
CSA
Certified HRCI-MISC (File No. LR29862) |
| |
35
--- 60A: |
| |
UL
Listed Class CD (File No. E71611) |
| |
CSA
Certified (File No. LR29862) |
| |
|
| AMPERE
RATINGS |
2/10 |
1 |
2 |
31/2 |
61/4 |
12 |
35 |
1/4 |
11/4 |
21/4 |
4 |
7 |
15 |
40 |
3/10 |
14/10 |
21/2 |
41/2 |
71/2 |
171/2 |
45 |
1/2 |
11/2 |
28/10 |
5 |
8 |
20 |
50 |
6/10 |
16/10 |
3 |
56/10 |
9 |
25 |
60 |
8/10 |
18/10 |
32/10 |
6 |
10 |
30 |
|
|
Example
part number (series & amperage): CCMR 40 |
| |
| RECOMMENDED
FUSE BLOCKS |
L60030C
series |
(CCMR
2/10 --- 30A) |
L60060C
series |
(CCMR
35 --- 60A) |
| Refer
to Fuse Block section of this catalog for additional information. |
