General Purpose Fuses
SLC Class G Fuses

480 VAC • Medium Time-Delay • 1/2 - 60 Amperes

SLC
SPECIFICATIONS
Voltage ratings: 600 Volts AC (1/2 - 20A)
480 Volts AC (25 - 60A)
Interrupting ratings: 100,000 amperes rms symmetrical
Ampere range: 1/2 - 60 amperes
Approvals:   UL Listed Class G Fuse per UL 248
(formerly UL 198C)
  (File No. E81895)
  CSA Certified HRCI-MISC (File No. LR29862)
  Federal Specification No. WF1814 (QPL)

AMPERE RATINGS
1/2
3
6
15
30
45
1
4
8
20
35
50
2
5
10
25
40
60
Example part number (series & amperage): SLC 10
