| SPECIFICATIONS |
| Voltage
ratings: |
AC: |
250
Volts (NLN, NLKP) |
| |
600
Volts (NLS) |
DC: |
250
Volts (NLN); |
| |
400
Volts (NLS 35 - 60A) |
| |
500
Volts (NLS 8 - 15A) |
| |
|
(NLS
225 - 600A) |
| |
600
Volts (NLS 1 - 7A) |
| |
|
(NLS
20 - 30A) |
| |
|
(NLS
70 - 200A) |
| |
|
| Interrupting
ratings: |
AC: |
50,000
amperes rms symmetrical (NLN/NLS) |
| |
10,000
amperes (NLKP) |
DC: |
20,000
amperes (NLN/NLS 1 - 60A) |
| |
50,000
amperes (NLN/NLS 70 - 600A) |
| |
|
| Ampere
range: |
1
- 600 amperes (NLN/NLS) |
| |
15
- 60 amperes (NLKP) |
| Approvals: |
|
NLN/NLS: |
UL
Listed Class K5 per UL 248 |
| |
(formerly
UL 198D) |
| |
(File
No. E81895) |
NLKP: |
UL
Listed Class H (File No. E81895) |
NLN**/NLS/NLKP: |
CSA
Certified per Spec No.59.1 |
| |
(File
No. LR29865)* |
*
NLKP series fuses meet CSA "Type P" requirement. |
**
Excludes NLN 15 - 60A |
| |
| AMPERE
RATINGS |
1 |
7 |
*
25 |
*
60 |
125 |
300 |
2 |
8 |
*
30 |
70 |
150 |
350 |
3 |
10 |
* 35 |
80 |
175 |
400 |
4 |
12 |
*
40 |
90 |
200 |
450 |
5 |
*
15 |
*
45 |
100 |
225 |
500 |
6 |
*
20 |
*
50 |
110 |
250 |
600 |
|
*
NLKP series available only in those amperages preceded by an asterisk. |
