General Purpose Fuses
KLDR Class CC Fuses

600 VAC • 1/10 - 60 Amperes

KLDR
SPECIFICATIONS
Voltage ratings:
AC:
 600 Volts
DC:
 300 Volts

Interrupting ratings:
AC:
 200,000 amperes rms symmetrical
DC:
 20,000 amperes
Ampere range: 1/10 - 30 amperes
Approvals:   UL Listed Time-Delay Class CC fuses per UL 198C
(File No. E81895)
  CSA Certified HRCI-MISC (File No. LR29862)

AMPERE RATINGS
1/10
1/2
14/10
28/10
56/10
10
1/8
6/10
11/2
3
6
12
15/100
3/4
16/10
32/10
61/4
15
3/16
8/10
18/10
31/2
7
171/2
2/10
1
2
4
71/2
20
1/4
11/8
21/4
41/2
8
25
3/10
11/4
21/2
5
9
30
4/10
Example part number (series & amperage): KLDR 56/10
