General Purpose Fuses
JLS Class J Fuses

600 VAC • Fast-Acting• 1 - 600 Amperes

JLS
SPECIFICATIONS
Voltage ratings: 600 Volts AC
Interrupting ratings: 200,000 amperes rms symmetrical
Ampere range: 1 - 600 amperes
Approvals: UL Listed Class J Fuses per UL 248
(formerly UL 198C)
  (File No. E81895)
  CSA Certified HRCI-J (File No. LR29862)
Federal Specification No. WF1814 (QPL)

AMPERE RATINGS
1
25
60
125
300
3
30
70
150
350
6
35
80
175
400
10
40
90
200
450
15
45
100
225
500
20
50
110
250
600
