| SPECIFICATIONS |
| Voltage
ratings: |
AC: |
300
Volts (JLLN); 600 Volts (JLLS) |
DC: |
125
Volts (JLLN 110 - 1200A); 300 Volts (JLLS) |
| Interrupting
ratings: |
AC: |
200,000
amperes rms symmetrical |
DC: |
20,000
amperes (JLLN 110 - 1200A) |
| |
|
(JLLS
1 - 1200A) |
| Ampere
range: |
1
- 1200 amperes |
| Approvals: |
|
AC: |
UL
Listed Class T per UL 248 |
| |
(formerly
UL 198H) |
| |
(File
No. E81895): JLLN/JLLS (1 - 800A) |
| |
UL
Recognized (File No. E71611): |
| |
JLLS
(900 - 1200A) |
| |
CSA
Certified HRCI-T (File No. LR29862): |
| |
JLLN/JLLS
(1 - 600A) |
DC: |
Additionally
UL Listed per UL 198L: |
|
JLLN
(110 - 1200A) (File No. E81895) |
|
JLLS
300 VDC is Littelfuse self-certified |
| |
| AMPERE
RATINGS |
1 |
20 |
45 |
90 |
175 |
350 |
700 |
2 |
25 |
50 |
100 |
200 |
400 |
800 |
3 |
30 |
60 |
110 |
225 |
450 |
1000 |
6 |
35 |
70 |
125 |
250 |
500 |
*1100 |
10 |
40 |
80 |
150 |
300 |
600 |
1200 |
15 |
|
|
|
|
|
|
|
*
JLLS only. |
