| SPECIFICATIONS |
| Voltage
ratings: |
AC: |
250
Volts (FLNR_ID); |
| |
600
Volts (FLSR_ID) |
DC: |
125
Volts (FLNR 1/10-30A); |
| |
125
Volts (FLNR_ID 35-600A); |
| |
300
Volts (FLSR_ID) |
| |
|
| Interrupting
ratings: |
AC: |
200,000
amperes rms symmetrical. |
| |
300,000
amperes rms symmetrical (Littelfuse self-certified) |
DC: |
20,000
amperes |
| |
|
| Ampere
range: |
1/10
- 600 amperes |
| Approvals: |
|
AC: |
UL
Listed Class RK5 Fuses per UL 248 |
| |
(formerly
UL 198E) |
| |
(File
No. E81895) |
| |
CSA
certified HRCI-R per C22.2 #106 |
| |
(File
No. LR29862) |
DC: |
FLNR:
UL Listed 125 Volts per UL 198L |
| |
(File
No. E81895) |
| |
FLNR_ID:
UL Listed 125 Volts per UL 198L |
| |
(File
No. E81895) |
| |
FLSR_ID:
UL Listed 300 Volts per UL 198L |
| |
(File
No. E81895) |
| |
MSHA
300 Volts listing |
Federal
Specification No. WF1814 (QPL) |
| |
|
| AMPERE
RATINGS |
1/10** |
6/10 |
18/10 |
4 |
8 |
30 |
80 |
225 |
1/8 |
8/10 |
2 |
41/2 |
9 |
35 |
90 |
250 |
15/100 |
1 |
21/4 |
5 |
10 |
40 |
100 |
300 |
2/10 |
11/8 |
21/2 |
56/10 |
12 |
45 |
110 |
350 |
1/4 |
11/4 |
28/10 |
6 |
15 |
50 |
125 |
400 |
3/10 |
14/10 |
3 |
61/4 |
171/2 |
60 |
150 |
450 |
4/10 |
11/2 |
32/10 |
7 |
20 |
70 |
175 |
500 |
1/2 |
16/10 |
31/2 |
71/2 |
25 |
75 |
200 |
600 |
|
**
FLNR Only |
|
